Description

5 EXTRA LONG STAINLESS

STEEL TUBELESS RIM VESPA

WHEEL HUB REPAIR BOLT

FRONT / REAR WHEEL LML

Hex socket button head repair bolt

brake drum front, rear,

for Vespa V50(10")/PV/ET3/PK/S

/XL/XL2/FL/ PX/T5/Cosa

Longer version of the Vespa hub stud (brake drum stud) M8 x 35mm with button head bottom so it can be tightened in place, ideal for use with wider aluminium wheel rims. Standard Studs are fitted from the front of the hub, and once wound into place the rear is swaged over to prevent them unwinding, to remove the old stud, first the sawged end of the original stud must be ground off on the rear of the hub, as this is wider then the hole and may damage the threads unless its removed, this bolt will replace the stud.

 Before the new bolt is in place a dab of thread lock is required to stay in place

OEM Numbers (for the purpose of comparison)  085914 - 229769 (PIAGGIO)

VESPA 50 / N 50 V5A1T 2T AC `63-`71 (D) 200001->

VESPA 50 L 50 V5A1T 2T AC `66-70 (D)

VESPA 50 R 50 V5A1T 2T AC `69-`83 (D) 752189 ->, 10"-rim

VESPA 50 S 50 V5SA1T 2T AC `63-`84 (CH) 69245->

VESPA 50 Special 50 V5A2T 2T AC '69-'72 (D) (10"-rims)

VESPA 50 Special 50 V5B1T 2T AC `72-`75

VESPA 50 Special 50 V5B3T 2T AC `75-`83

VESPA 50 Special Elestart 50 V5B4T 2T AC '75-'76 (D)

VESPA 50 Special Elestart 50 V5B2T 2T AC `72-`75 (D)

VESPA 50 Special Elestart 50 V5B2T 2T AC `72-`75

VESPA 50 Special Elestart 50 V5A3T 2T AC '69-'72 (D) (10"-rims)

VESPA 50 SR / Sprinter 50 V5SS2T 2T AC `71-`79 (D) 10001->

VESPA 50 SS / Super Sprint 50 V5SS1T 2T AC `65-`71

VESPA 90 90 V9A1T 2T AC `63-`84 (RI) 149500->

VESPA 90 Racer 90 V9SS2T 2T AC `71-`74

VESPA 90 SS Super Sprint 90 V9SS1T 2T AC `65-`71

VESPA 100 (UK) / 100 Sport (US) 100 V9B1T 2T AC `78-`90 (CDN) ->25396

VESPA 100 (UK) / 100 Sport (US) 100 V9B1T 2T AC `78-`90 (RI)

VESPA 100 (UK) / 100 Sport (US) 100 V9B1T 2T AC `78-`90 50001 ->

VESPA 125 125 VMA1T 2T AC `65-`67

VESPA 125 Primavera 125 VMA2T 2T AC `67-`83 (CDN) ->089800

VESPA 125 Primavera 125 VMA2T 2T AC `67-`83 (USA) ->089800

VESPA 125 Primavera 125 VMA2T 2T AC `67-`83

VESPA 125 Primavera ET3 125 VMB1T 2T AC `76-`90

VESPA 125 Super 125 VNC1T 2T AC `65-`69

VESPA 150 Super 150 VBC1T 2T AC `65-`79

VESPA COSA 1 150 VLR1T 2T AC `87-`90 rear

VESPA COSA 1 200 VSR1T 2T AC `88-`91 rear

VESPA COSA 1 125 VNR1T 2T AC `88-`91 rear

VESPA COSA 2 150 VLR2T 2T AC `91- rear

VESPA COSA 2 125 VNR2T 2T AC `91- rear

VESPA COSA 2 200 VSR1T 2T AC `90-`96 rear

VESPA P125X 125 VNX1T 2T AC `77-`82

VESPA P150 S 150 VBX1T 2T AC `78-`90

VESPA P150X / PX150 E 150 VLX1T 2T AC `78-`85

VESPA P200E / PX200 E 200 VSX1T 2T AC `77-`83

VESPA P80 / P80 E (Frankreich) 80 V8A1T 2T AC `80-`84 front

VESPA P80 / P80 E (Frankreich) 80 V8A1T 2T AC `80-`84

VESPA P80X/PX80 E 80 V8X1T 2T AC `81-`83

VESPA PK 50 50 V5X1T 2T AC `82-`84 (D)

VESPA PK 50 50 V5X1T 2T AC `82-`84 (D). 17203 ->17512, model XL

VESPA PK 50 50 V5X1T 2T AC `82-`84 (I)

VESPA PK 50 50 V5X1T 2T AC `82-`84 rear

VESPA PK 50 / S Automatica / Elestart 50 VA51T 2T AC `84-`86 (D) (ETS supsension arm)

VESPA PK 50 S / Elestart 50 V5X2T 2T AC `82-`84 (D)

VESPA PK 50 S / Elestart 50 V5X2T 2T AC `82-`84 (I)

VESPA PK 50 S / Elestart 50 V5X2T 2T AC `82-`84 rear

VESPA PK 50 S Lusso / Elestart 50 V5X2T 2T AC `85-`88 front

VESPA PK 50 S Lusso / Elestart 50 V5X2T 2T AC `85-`88 rear

VESPA PK 50 SS / Elestart 50 V5S1T 2T AC `83-`86 front

VESPA PK 50 SS / Elestart 50 V5S1T 2T AC `83-`86 rear

VESPA PK 50 XL / Elestart 50 V5X3T 2T AC `85-`90 (D), (125 steering column )

VESPA PK 50 XL / Elestart 50 V5X3T 2T AC `85-`90 (I)

VESPA PK 50 XL / Elestart 50 V5X3T 2T AC `85-`90 rear

VESPA PK 50 XL FL 50 V5N1T 2T AC `90- rear

VESPA PK 50 XL HP 50 V5N2T 2T AC `91-`91 rear

VESPA PK 50 XL N NUOVA 50 V5X5T 2T AC `89-`90 front

VESPA PK 50 XL N NUOVA 50 V5X5T 2T AC `89-`90 rear

VESPA PK 50 XL Rush / Elestart 50 V5X4T 2T AC `88-`90 front

VESPA PK 50 XL Rush / Elestart 50 V5X4T 2T AC `88-`90 rear

VESPA PK 50 XL2 / Elestart 50 V5X3T 2T AC `90- (D), conform to V5N1

VESPA PK 50 XL2 / Elestart 50 V5X3T 2T AC `90- rear

VESPA PK 80 S / Elestart 80 V8X5T 2T AC `82-`86 front

VESPA PK 80 S / Elestart 80 V8X5T 2T AC `82-`86 rear

VESPA PK 80 S Automatica / Elestart 80 VA81T 2T AC `84 front

VESPA PK 80 S Lusso / Elestart 80 V8X5T 2T AC `85-`88 rear

VESPA PK100 S / Elestart 100 V9X1T 2T AC `82-`84 rear

VESPA PK100 XL 100 V9X2T 2T AC `86-`90 rear

VESPA PK125 125 VMX1T 2T AC `82-`85 front

VESPA PK125 125 VMX1T 2T AC `82-`85 rear

VESPA PK125 ETS / Elestart 125 VMS1T 2T AC `84-`85 front

VESPA PK125 ETS / Elestart 125 VMS1T 2T AC `84-`85 rear

VESPA PK125 N NUOVO (FL) 125 VMX7T 2T AC `90-`91 front

VESPA PK125 N NUOVO (FL) 125 VMX7T 2T AC `90-`91 rear

VESPA PK125 S / Elestart 125 VMX5T 2T AC `82-`84 front

VESPA PK125 S / Elestart 125 VMX5T 2T AC `82-`84 rear

VESPA PK125 S Automatica / Elestart 125 VAM1T 2T AC `83-`84 front

VESPA PK125 XL / Elestart 125 VMX6T 2T AC `86-`90 front

VESPA PK125 XL / Elestart 125 VMX6T 2T AC `86-`90 rear

VESPA PK125 XL2 125 VMX6T 2T AC `90- front

VESPA PK125 XL2 125 VMX6T 2T AC `90- rear

VESPA PX 80 E Lusso/ EFL/ Arcobaleno / Elestart 80 V8X1T 2T AC `83-`90

VESPA PX100 E 100 VIX1T 2T AC `83-`84

VESPA PX125 2011/ 30 Jahre 125 ZAPM74100 2T AC `11-

VESPA PX125 CAT 125 ZAPM50100 2T AC `07-

VESPA PX125 E 125 VNX2T 2T AC `81-`83

VESPA PX125 E '98 / Millenium 125 VNX2T 2T AC `98-`05

VESPA PX125 E Lusso/EFL/Arcobaleno / Elestart 125 VNX2T 2T AC `83-`97

VESPA PX150 2011 150 ZAPM74200 2T AC `11-

VESPA PX150 E '98 / Millenium 150 VLX1T 2T AC `98-`05

VESPA PX150 E Lusso/EFL/Arcobaleno / Elestart 150 VLX1T 2T AC `83-`97

VESPA PX200 E '98 / Millenium 200 VSX1T 2T AC `98-`05

VESPA PX200 E Lusso/ EFL/ Arcobaleno / Elestart 200 VSX1T 2T AC `83-`97

VESPA T5 / Elestart 125 VNX5T 2T AC `85-`90

VESPA T5 Classic 125 VNX5T 2T AC `92-`95
